Volume
20L ~ 30000L
-
Height to diameter ratio
Customize according to customer needs
-
Cultivate objects
Bacteria, yeast
-
Cleaning/sterilization method
In-place sterilization
-
Tank material
Stainless steel 316L Ra<0.4um EP
-
Stirring
Top/bottom installation, double end face mechanical seal and mechanical stirring; blade type and speed are customized according to requirements; blade height can be adjusted, and the assembly method is no dead angle assembly;
-
Intake and exhaust
A sterile filter with a stainless steel shell, equipped with a vent tube and a gas distributor, the maximum ventilation volume can reach 3m, and an oxygen pipeline is optional
-
Temperature control
The closed-cycle TCU system adopts indirect heat exchange between steam and cooling water, and achieves precise temperature control, air elimination and actual elimination through cascade PID.
-
pH
Using smart PH electrodes; associated control with acid and alkali replenishment;
-
Dissolved oxygen
Use smart, optical DO electrode; associated control with stirring, ventilation, and oxygen;
-
Defoaming
Related control of defoaming agent pump and defoaming electrode, automatic defoaming
-
Supplement
Provide customized replenishment strategy;
-
Control system
Provide PLC and PCS7 two automatic control system architectures
-
Extended functions
Reserved digital and analog input/output interfaces (no setting), the interface can be connected to external equipment (such as balance, turbidity, etc.)
-
Optional
Online turbidity detection; online exhaust gas analysis; methanol concentration/ethanol concentration monitoring; weighing\liquid level monitoring;
